X-P MX Universal nails (collated)

Configurator
Technical Data
Documents
Features & Applications
Related Products
X-P MX (87188)
L091529_v1_cropped (111059)
DX 5 MX (87228)
DX 5 MX (87200)
DX 5 MX (87252)
DX 5 MX (84719)

Ultimate-performance collated nails for fastening to concrete and other base materials using powder-actuated tools

  • Base materials: Concrete (soft), Concrete (tough), Masonry (solid limestone brick)
  • Minimum thickness of base material (concrete): 80 mm
  • Corrosion protection: Galvanised zinc coated <20 µm
ultimate

Customers also searched for X-P, Nails, Concrete, Pins or Collated.

Choose options

Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

Discounted net
For Pricing

Please contact us on 0800 444 584

No products available

Please Contact us to find a solution.

Technical Data

Base materials
Concrete (soft), Concrete (tough), Masonry (solid limestone brick)
Minimum thickness of base material (concrete)
80 mm
Corrosion protection
Galvanised zinc coated <20 µm
Environmental conditions
Dry indoor
Material
Carbon steel
Fastener shank diameter
4 mm
Washer size
8 mm
Point type
Long conical tip
Approvals
ICC-ES
Product class
Ultimate

Documents

Technical information
Approval document
pdf Direct Fastening Technology Manual, English [ 6 MB ]
pdf X-P Data Sheet, English [ 2.1 MB ]

Features & Applications

Features

  • Designed for fastening on tough concrete (tested and approved for 8000 psi concrete, up to 1" embedment) and steel
  • Long conical nail tip designed for best drivability in tough concrete and steel
  • Highest hardness (59 HRC) for best penetration in tough concrete or steel
  • Provides effective embedment depths of 3/4", 1", 1 1/4" and 1 1/2" when used with tracks up to 14 ga thick
  • Highest load performance on tough concrete and steel

Applications

  • Fastening to soft or tough concrete or steel
  • Fastening metal track for plasterboard/dry lining to concrete
  • Fastening wall ties
  • Fastening wood to concrete
  • Setting up formwork and safety barriers

For approval or certificate information, please see individual items.
